Tar River Implements | Ground Tools
Tar River Box Blades
Tar River Implements has Box Blades available in five popular sizes.
Additional Information
The New Sub-Compact Box Blades come in 48” & 60” working widths and 1/4” side plates. The Medium Duty Box Blades come in 60”, 72”, and 84” working widths with 1/2” side plates (3/8” for 60” model). With its clevis hitches and durable design, the Tar River Box Blade is a great tool for all around dirt maintenance. The front and rear replaceable 6” scraper blades allow for quick and easy replacement making the Tar River line of box blades an excellent choice for all your dirt moving needs!
Other Characteristics
1/2" Side Plates on 72" & 84" models!!! Heavy, Durable Design
Specifications
Model | Working Width | M. Board Height | Side Plate Thickness | A-Frame Thickness | # Shanks | Max HP | Weight lbs |
Sub-Compact Models | |||||||
BB4SC | 48" | 14" | 1/4" | 1/2" | 4 | 24 | 307 lbs |
BB5SC | 60" | 14" | 1/4" | 1/2" | 5 | 24 | 322 lbs |
Medium Duty Models | |||||||
BB5 | 60" | 18" | 3/8" | 1/2" | 5 | 50 | 512 lbs |
BB6 | 72" | 18" | 1/2" | 1/2" | 6 | 50 | 596 lbs |
BB7 | 84" | 18" | 1/2" | 1/2" | 7 | 50 | 664 lbs |
