Tar River Attachments | Grapples
CLAW GRAPPLE
CCG54, CCG55-AR & CCG66-AR Claw Grapples are constructed of 3/8” A-36 Steel. Cylinder has 2” bore & 10” stroke. Units Come Standard With Quick Connect couplers & Hoses. The "CCG" series Claw Grapple is rated for tractors under 30HP.
Specifications
| Model | Description | Width | Mount | Weight | Tractor HP | Construction | Number of Hyd. Cylinders |
| CCG54 | Compact Claw Grapple | 54" | Universal Skid Steer | 300 lbs. | less than 30 HP | A-36 Steel | 1 |
| JDCCG54 | Compact Claw Grapple | 54" | John Deere mount | 300 lbs. | less than 30 HP | A-36 Steel | 1 |
| CCG55-AR | Compact Claw Grapple | 55" | Universal Skid Steer | 205 lbs. | less than 30 HP | A-36 Steel | 2 |
| JDCCG55-AR | Compact Claw Grapple | 55" | John Deere mount | 192 lbs. | less than 30 HP | A-36 Steel | 2 |
| CCG66-AR | Compact Claw Grapple | 66" | Universal Skid Steer | 220 lbs. | less than 30 HP | A-36 Steel | 2 |
| JDCCG66-AR | Compact Claw Grapple | 66" | John Deere mount | 210 lbs. | less than 30 HP | A-36 Steel | 2 |
| SDCG60 | Standard Duty Claw Grapple | 60" | Universal Skid Steer | 367 lbs. | up to 50 HP | A-36 Steel | 2 |
| SDCG66 | Standard Duty Claw Grapple | 66" | Universal Skid Steer | 387 lbs. | up to 50 HP | A-36 Steel | 2 |
| SDCG72 | Standard Duty Claw Grapple | 72" | Universal Skid Steer | 407 lbs. | up to 50 HP | A-36 Steel | 2 |
Additional Images
