Tar River Attachments | Grapples

CLAW GRAPPLE

CCG54 Claw Grapple constructed of 3/8” A-36 Steel. CCG55-AR & CCG66-AR constructed of AR400 steel. Cylinder has 2” bore & 10” stroke. Units Come Standard With Quick Connect couplers & Hoses. The "CCG" series Claw Grapple is rated for tractors under 30HP.

Specifications
MODEL DESCRIPTION WIDTH MOUNT WEIGHT Tractor HP Construction Number of Hyd. Cylinders
CCG54 Compact Claw Grapple 54" Universal Skid Steer 300 lbs. less than 30 HP A-36 Steel 1
JDCCG54 Compact Claw Grapple 54" John Deere mount 300 lbs. less than 30 HP A-36 Steel 1
CCG55-AR Compact Claw Grapple 55" Universal Skid Steer 205 lbs. less than 30 HP AR400 Steel 2
JDCCG55-AR Compact Claw Grapple 55" John Deere mount 192 lbs. less than 30 HP AR400 Steel 2
CCG66-AR Compact Claw Grapple 66" Universal Skid Steer 220 lbs. less than 30 HP AR400 Steel 2
JDCCG66-AR Compact Claw Grapple 66" John Deere mount 210 lbs. less than 30 HP AR400 Steel 2
SDCG60 Standard Duty Claw Grapple 60" Universal Skid Steer 367 lbs. up to 50 HP AR400 Steel 2
SDCG66 Standard Duty Claw Grapple 66" Universal Skid Steer 387 lbs. up to 50 HP AR400 Steel 2
SDCG72 Standard Duty Claw Grapple 72" Universal Skid Steer 407 lbs. up to 50 HP AR400 Steel 2
Additional Images
